Single Battery Multifunctional Tester

Multifunctional Battery Tester

Purpose

Suitable for testing various electrical performance test items of high, medium and low-density storage batteries.

Features

Controlled by a dedicated microcomputer, equipped with an LCD screen, and compatible with PC connection.

Easy to operate: Program writing, viewing, starting, stopping, and other operations can be performed via the device's control panel or programs downloaded from a PC.
Features intelligent program control, with precise dedicated microcomputer control, LCD screen display, and PC connectivity.
User-friendly operation: Supports program writing, viewing, starting, stopping, and other functions through the device's control panel or PC-downloaded programs.
Records test data, enables independent operation without a PC, and has power-off data storage and automatic resumption of operation after power-on.

Functions

Capable of testing comprehensive performances of storage batteries, including capacity, charge acceptance, charge retention, discharge performance, cycle life, and overcharge/overdischarge capability.
Allows arbitrary setting of test process programs and can store multiple programs for later use.
Features multiple working modes: constant voltage, constant current, constant voltage with current limit, constant current with voltage and time limits, constant resistance, constant power, standing, and cycling.
Provides various functions such as run, stop, pause, and step skip.
Supports multi-machine networking to achieve resource sharing.
Data can be uploaded to a PC, enabling the generation of various data reports and curve reports.

Technical Specifications

Voltage Control Range: 0.5%~100%
Current Control Range: 0.5%~100%
Current & Voltage Regulation Accuracy: ≤±0.5% F.S
Time Control Accuracy: ≤10S/24h
Minimum Data Acquisition Interval: 1S

Specification Sheet

Model	Discharge Current（A）	Charge Current(A)	Charge Voltage（V）	Discharge Voltage（V）	Battery Voltage(V)	Dimension(cm)			Weight (Kg)
Model	Discharge Current（A）	Charge Current(A)	Charge Voltage（V）	Discharge Voltage（V）	Battery Voltage(V)	W	D	H	Weight (Kg)
MTL-TSA20V/5A/5A	5	5	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/10A/10A	10	10	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/20A/20A	20	20	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/30A/30A	30	30	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/50A/50A	50	50	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/100A/100A	100	100	4.5~18	4.5~14	6,12	76	76	200	150
MTL-TSA20V/20A/10A	20	10	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/30A/10A	30	10	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/50A/10A	50	10	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/60A/10A	60	10	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/100A/10A	100	10	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/200A/20A	200	20	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/300A/30A	300	30	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/500A/50A	500	50	4.5~18	4.5~14	6,12	76	76	200	200
MTL-TSA20V/1000A/100A	1000	100	4.5~18	4.5~14	6,12	——	——	——	200
MTL-TSA20V/2000A/200A	2000	200	4.5~18	4.5~14	6,12	——	——	——	200
MTL-TSA20V/3000A/300A	3000	300	4.5~18	4.5~14	6,12	——	——	——	200
MTL-TSB20V/100AV/10A	100	10	0.8~18	0.8~14	2,6,12	76	76	200	300
MTL-TSB20V/200A/20A	200	20	0.8~18	0.8~14	2,6,12	76	76	200	300
MTL-TSB20V/300A/30A	300	30	0.8~18	0.8~14	2,6,12	76	76	200	300
MTL-TSB20V/500A/50A	500	50	0.8~18	0.8~14	2,6,12	76	76	200	300
MTL-TSB20V/1000A/100A	1000	100	0.8~18	0.8~14	2,6,12	——	——	——	400
MTL-TSB20V/2000A/200A	2000	200	0.8~18	0.8~14	2,6,12	——	——	——	400
MTL-TSB20V/3000A/300A	3000	300	0.8~18	0.8~14	2,6,12	——	——	——	400
